YS TOOLS
12" 96T HiATB Saw Blade – 25° Tooth Angle for Melamine & Laminated Panels | No Scoring Blade Required
12" 96T HiATB Saw Blade – 25° Tooth Angle for Melamine & Laminated Panels | No Scoring Blade Required
Couldn't load pickup availability
305 mm 96T HiATB Saw Blade — 25° Top Bevel
Fine-finish HiATB saw blade for melamine and laminated panels. The 25° high alternate top bevel geometry helps reduce surface chipping and can produce clean cuts without a separate scoring blade in suitable applications.
Technical Specifications
| Specification | Details |
|---|---|
| Diameter | 305 mm |
| Teeth | 96 |
| Tooth geometry | High alternate top bevel (HiATB) |
| Top bevel angle | 25° |
| Bore | 25.4 mm (1") |
| Kerf width | 3.4 mm |
| Plate thickness | 2.6 mm |
| Maximum speed | 6,000 RPM |
Suitable Materials
Melamine-faced panels; laminated panels; MDF; particleboard; plywood; veneered boards.
Selection & Setup
Use on compatible machines accepting a 305 mm blade and 25.4 mm arbor bore. Results without scoring depend on the panel surface, blade condition, machine alignment and feed. Check the finish on a sample of your material.
Maximum speed is a limit, not a recommended operating speed. Follow the blade markings and your machine manufacturer's operating instructions.
Need Help Choosing?
Contact YS Tools with your machine model, material and required dimensions for selection support.
